Everrising Machinary Corporation

Product :

	Product Name:NC milling machine

Product Description:

*Swing and distance:
Swing over bed (radius)-- 510mm(20")
Center height -- 255mm(10")
Swing over cross slide (dia)-- 295mm
(11.6")
Distance between centers --
1000mm(40"),1500mm(60"),
2000mm(80")
*Spindle:
Spindle speeds --
3 ranges / H:451~2000rpm
M:141~450rpm
L:30~140rpm
(infinitely variable)
Spindle bore -- 85mm(3 5/16")
Spindle motor -- AC 10HP (7.5KW)
Tape in spindle -- MT6x4
*Saddle:
Longitudinal travel(Z axis)
750mm(30")
1250mm(50")
1650mm(66")
Cross slide travel(X axis)-- 280mm(11")
*Tailstock:
Travel -- 150mm(6")
Taper -- MT5
* Remarks:
1. Special specifications are
available by order (minimum:
1 x 20¡¦ container)
2. Specifications are subject to
change for improvement without
notice.
3. When mounting hydraulical turret
on above model, the distance
between centers will be reduced for 150mm.
4. After mounting hydraulic chuck,the spindle bore will be reducedfor 11mm or 13mm.
8"/10" hydraulic chuck : 52mm -->41mm/39mm
8"/10" hydraulic chuck : 58mm -->47mm/45mm
8"/10" hydraulic chuck: 85mm -->74mm/72mm
12" hydraulic chuck:104mm -->91mm

Contact Information:

Company Name:	Everrising Machinary Corporation
Contact Person:	----------
Address:	7F, No.63, Section 4, Hsin-Yi Rd., Taipei, Taiwan.
E-Mail:
Telephone:	886-2-27043366
Mobile:	------------
Fax:	886-2-27034056
Web Site:	www.everrising.com.tw
