| Tsyr Tzun Industrial Co., Ltd. |
|
| |
| |
|
| |
| |
 |
|
Automatic step feed:
Efficiently to discharge the scrap with automatic step feeding device.
Control device of cutting force:
In order to prevent the cutting tools from being over worn out, this device can control the feeding unit, for example while cutting a hard or bad materials of steel, or the scrap in a deep hole are not easy to be discharged. This device can stop feeding temporally, until the resistance disappeared, and it will feed automatically continually until completed.
Protective function of cutting force control device:
If operator forget to lock the fixing bolt, after drilling through a hole the automatic feed function will be continual until the end, under this function, both the gear cylinder and machine body won't be damaged.
Equipped with automatic stop device:
After drilling through a hole, the automatic feed device will back to origin soon and the power for motor will be cut off by this function automatically. Prepare for next drilling.
Resistance indicator device:
This device can detect the resistance force of cutter while cutting, operator can know whether it's necessary to replace the cutter or not by this function.
Coolant tank:
Ingrated with the machine body. Lowers the damage resulting from impact efficiently. |
|
|
|
|
| |
|
|
| |
| |
 |
|
