| Sheng Jyi Machinery Industrial Co., Ltd. |
|
| |
| |
|
| |
| |
 |
|
Printing carriage to be driven via linkage mechanism, vibration free for extremely stable printing
Equipped with play-free and fine-register adjustment in X-Y direction for precise color process
Able to set up the floodbar pre-coated with ink or coated with ink when printing to minimize screen clogging
Constant pressure across the length of squeegee and floodbar achieved by the pressure equalizer system for extremely stable printing
Easy to install/detach the squeegee and floodbar by simple and firm clamps ensuring stable printing pressure
Angular setting of squeegee and floodbar for optimal printing quality
Printing / flood coating speed to be controlled independently by high grade frequency inverter
Adopting PLC as main electrical control system, easy to maintain
Synchronized peeling system allowing the screen to peel away from the substrate without shadow, deformation and screen-sticking even the different viscosity of ink and different tension of screens
Pedal switch with 2-stage function, to bring vacuum beforehand then to start printing, for placing substrate correctly
With angle adjustments for squeegee and floodbar, independently set for superior print quality
Equipped with automatic unloading device to increase efficiency |
|
|
|
|
| |
|
|
| |
| |
 |
|
