BUILDING SPEED 40sec./1pc
REVOLUTION OF DRUM 35 r.p.m.
NYLON CORD 1PLY OVERLAPE
UNDER STITCHER RUBBER PROFILE ROLL
OPTIONAL ATTACHMENT .NUMBERING DEVICE .CHAFER SERVICER
(FOR SKIN WALL) .HOT KNIFE HEATER
(1)Beadwire automatic carry to building drum by beadwire holder.
(2)Tread with automatic cutting device by hot knife, the length is pre-setting by rotary
.....encorder.
(3)The machine is equipped special design with patent slide expand type building
.....drum. The building drum has very good precision and no wear off trouble for
.... long terms operation.
(4)The building drum has special design with patent turn up fingers device (36 pcs
.... turn up fingers on the one side of durm , total 72pcs in one durm)
(5)The building drum has special design with patent no gap rubber band which will
.....produce very tough green tire on bead position so it can reduce the blister problem
.....on the sidewall and bead position of cured tire.
(6)The building drum has special design with patent for three steps expansion.
.... Ist step is reduction to minimum diameter for easy to take out the green tire from
.....building drum, 2nd step is expansion to middle diameter for apply the nylon cord
.....& bead setting.
.....3rd step is expansion to excatly diameter & bead goes into bead groove then
.....overlape turn up then apply tread & stitching the tread.
(7)The splicing position of nylon cord & tread is controlled to be applied in the
.....opposite side to get the better balance of tire.
(8)Tread stitching device which will more effectly stitch tread to stick tightly with cord.
(9)Bead setting ring equipped with strong magnets will rapidly and precisely hold bead
.....wire on right position. |
|
|
|
|
| |
|
|
| |
| |
 |
|
