Extruder with reduction hilical gearbox is driven by AC or DC motor with frequency inverter.
Accumulator head of twin geart design with polymer overlap gives high quality stress free parison.
Injection and servo parison actuator device to execute material purge and parison programming.
Clamping unit of BT & LK serise available ad choice, both with tie bar-less design to provide easy access for mold installation and removal.
BT series clamping unit uses one hydraulic cylinder fixed at the center of each clamping platen and incorporates connecting rack and pinion for clamp platern closing and opening.
LK series clamping unit has 4 or 6 hydraulic cyliders situated at the side of clampin platen and operated synchronously and with electronic-hydraulic master-slave control system for the locking bars to give exact welding and precisely defined clampin force distribution.
Two separate power packs for clamping unit & parison injection, with accumulator for energy saving in high speed clamping stroke.
Robot arm of either pneumatic or hydraulic type to take the product from the mold to the deflashing station.
Photocell located at clamping plate as a standard safety device.
Machine fully controlled by multi-processor of Barber Colman, Maco 6000.
Moog servo valve with injection cylinder for 100 points parison thickness control. |
|
|
|
|
| |
|
|
| |
| |
 |
|
