Independent Pincer Pulling:
Separately adjustable pulling for left/right shoe,
Giving natural tension distribution of upper.
2-stage Nozzle Spread:
Easy control of cement path, creating effective cement application path.
Pincer Inward pulling:
Extra inward pulling after pincers grasp the upper, providing tight fit of upper against the last.
Overlapped Seat & Side Lasting:
Smooth connection between seat & side, perfecting lasting quality.
Powered Pincer Position Adjustment:
Slight touch on the switch, pincers can be moved to the best pulling position.
Encoder Controlled Side Lasting:
Accurate cement path, creating better side lasting results.
Auto-balanced Heel Band Gap:
Balanced gap with wipers, shaping perfect lasting results on the heel.
Touch Screen Interface:
User-friendly, integrated controls, making operations and maintenance easy.
Powered Heel Band Position Adjustment:
Guided by user-friendly oriented design principle, heel band can be adjusted with great ease.
Computerized Control:
PLC control device, controlling the machine with maximum flexibility.
Separate Lasting Fingers:
Combined with unique hydraulic system, resulting in tight ball-area lasting.
Operating Parameters Storage:
Saving up to 30 files, cutting time needed for different shoe style.
Motor-driven Cement Feeding:
Stable and adjustable cement quantity, keeping sound cement quality.
Automatic Error Warning:
Warnings on various possible errors, providing quick repair solutions.
Active Cement Stop Device:
Quick start/stop response of cement application, preventing leakage.
SPECIFICATIONS
Fingers
EF-526MA:5
EF-526MB:4
Machine Size (LxWxH)
1550x1400x1900 mm
Packing Size (LxWxH)
1700x1520x2100 mm
Capacity (8Hr)
1500 Pairs
N.W.
1180 kgs
G.W.
1330 kgs
Power
3 HP
Heating
660W
|
|
|
|
|
| |
|
|
| |
| |
 |
|
