Specifications Metric:MM Imperial:inch
X / Y / Z Travel 1010 / 500 /520 39.76" / 19.60" / 20.47"
Table overall size 1200 X 450 47.24" X 17.72"
T-slots( width/No/pitch ) 18 / 3 / 75 0.7" / 5 / 2.95"
Table max. loading 500KGS 1100LBS
Floor to table surface 880 34.65"
Spindle motor 5.5KW / 7.5KW 7.6HP / 10HP
Spindle speed 8000 RPM
Spindle taper BT#40
X / Y / Z feed motor 2KW 2.6HP
X / Y / Z constant torque 120KG-CM 8.4FT-LB
X / Y / Z Rapid traverse 12M/MIN 472"/MIN
X / Y / Z Cutting feedrate 1-5000MM/MIN 0.04"-196.85"/MIN
No. of ATC tools 20
Max. tool(dia./weight/length) 100 / 7KG / 250 3.93" / 15.4LBS / 9.84"
Machine weight 5500KGS 12100LBS
Coolant pump motor 0.375KW 0.5HP
Lubrication pump 4WATT
Power requirement 20KVA
|
|
|
|
|
| |
|
|
| |
| |
 |
|
