Model KKE-430 KKE-530 KKE-440 KKE-540 KKE-550
Moulding size
(LxHxW) 450x300x150
mm 500x300x200
mm 450x400x250
mm 500x400x300
mm 550x400x350
mm
Shell moulding size
(LxHxW) 370x280x100
mm 420x280x150
mm 370x380x200
mm 420x380x250
mm 470x380x300
mm
Operating style Individual operating-single auto cycle operating-progressive auto operating
Forming capacity 20-90seconds/cycle
Heating style By LPG or electric heating
Max. blowing volume 10kg 15kg 20kg 25kg 25kg
Sand storage volume 250kg 300kg 300kg 300kg 450kg
Operating pressure 5-6kg/cm2
Sand blowing pressure 1-4kg/cm2
Voltage AC-220V/380V/50/60HZD3P
Cooling water capacity 2-4m/hr
Air piping orifice 3/4" 3/4" 3/4" 3/4" 1"
Machine weight 2500kg 2800kg 3000kg 3200kg 3500kg
Machine size
(LxHxW) 2560x2500x3500
mm 2650x2500x3550
mm 2860x2500x3600
mm 3100x2500x3650
mm 3500x2500x3700
mm
|
|
|
|
|
| |
|
|
| |
| |
 |
|
