Model KKF38-18 KKF40-20 KKF45-25 KKF50-28
Shell moulding size (LxHxW) 350x160x200mm 380x180x200mm 420x220x220mm 480x260x250mm
Operating style Individual operating-single auto cycle operating-progressive auto operating
Forming capacity 20-90seconds/cycle
Heating style Electric heating
Max. blowing volume 3kg 4kg 5kg 6kg
Sand storage volume 15kg 15kg 20kg 25kg
Operating pressure 5-6kg/cm2
Sand blowing pressure 2-5kg/cm2
Voltage AC-220V/380V/50/60HZD3P
Cooling water capacity 2-4m3/hr
Air piping orifice 3/4" 3/4" 3/4" 3/4"
Machine weight 2100kg 2300kg 2500kg 2700kg
Machine size (LxHxW) 2500x2150x2400mm 2500x2200x2500mm 2600x2200x2600mm 2600x2300x2600mm
Specifications or dimensions subjected to change, without prior notice.
|
|
|
|
|
| |
|
|
| |
| |
 |
|
