Specifications Metric:MM Imperial:inch
X / Y / Z Travel 1400 / 700 /610 55.12" / 25.6" / 24"
Table overall size 700 X 1500 27.56" X 59.06"
T-slots( width/No/pitch ) 18 / 5 / 100 0.71" / 5 / 3.94"
Table max. loading 1500KGS 3300LBS
Floor to table surface 875 34.45"
Spindle motor 11KW / 15KW 15HP / 20HP
Spindle speed 40-4000 RPM
Spindle taper BT#50
X / Y / Z feed motor 3.75KW 5HP
X / Y / Z constant torque 240KG-CM 16.5FT-LB
X / Y / Z Rapid traverse 10M/MIN 393.7"/MIN
X / Y / Z Cutting feedrate 1-5000MM/MIN 0.04"-197"/MIN
No. of ATC tools 20
Max. tool(dia./weight/length) 125 / 15KG / 300 4.92" / 33LBS / 11.81"
Machine weight 10000KGS 22000LBS
Coolant pump motor 0.86KW 1.1HP
Lubrication pump 15WATT
Power requirement 25KVA
|
|
|
|
|
| |
|
|
| |
| |
 |
|
