Computer & PLC controller with touch screen panel:
Multifunctional & humanize operation.
Touch panel, in both Chinese & English mold.
Automatic pneumatic bobbin doffing system.
Variable traverse adjustment.
Density of thread layer adjustment.
Program storage function, for memorize different winding setting.
Production counter.
Revolution counter.
500~1900 rpm, spindle speed is adjustable.
0~60 rpm lube roller is adjustable.
1~100% auto release tension control.
High efficiency, diversity products, easy operation
Automatic doffing device
The winded package is doffing by pneumatic doffing system, the doffing time takes 12 seconds.
Bobbin compartment is adjustable, suitable for diffrent size of bobbins.
Veriable traverse adjustment
Traverse length is adjustment through the knob ourside the cam box.
Density of thread layer adjustment
The distance between the adjacent winds can be steplessly adjusted according to yam count by means of a hand wheel.
The maximum possible amount of thread is wound onto the under-bobbin.
Lube system (cold type)
LIquid lube system, Automatic roller speed changer.
Lube roller winding direction is adjustable.
For Shoes & Garment Factories
The majority of stoppages on industrial sewing and embroidery machinery is caused by thread breakages attributable to under bobbins resulting in lower quality and production losses. Therefore, uniform quality and running canditions of the under bobbin, are of utmost importance. The high quality bibbins from our automatic winders improve sewing machine efficiency considrably. The superior quality of bobbins allow the operator to locate the thread end easily reducing handing time and costs. The maximum possible amount of thread is wound into a wide range of different bobbins sizes.
All sewing thread manfactures have their own assortment of bobbin sizes to meet their cumstomer" requirements. The manul production of under of under bobbins in the majority of cased is unprofibable. Our aotomatic under bobbin winders suitable for a wide range of different bobbins sizes. |
|
|
|
|
| |
|
|
| |
| |
 |
|
