PRESSURIZING CAPACITY (ton) 100 200 300
RAISING CAPACITY (ton) 40 47 55
SLIDE STROKE (mm) 1200 1800 2500/3000
OPEN HEIGHT DAYLIGHT(mm) 1200 1800 2500/3000
SLIDE AREA (mm) 1300*1000 2000*1500 3000*2000
BOLSTER AREA (mm) 1300*1000 2000*1500 3000*2000
SLIDE LOWERING VELOCITY mm/sec 70-100 130 130
SLIDE SLOW DOWN VELOCITY mm/sec 5-20 5-20 5-20
SLIDE RAISING VELOCITY mm/sec 60 135 135
SLIDE SLOW UP VELOCITY mm/sec 5-15 15-60 15-60
TURN REVERSE 180 180 180
MOTOR 10HP 40HP 60HP |
|
|
|
|
| |
|
|
| |
| |
 |
|
