1. Cable port:
Two sizes of cable port are available:
50 mm and 100 mm.
2. Doors:Two types of doors are available: double swing door (140W-180H cm) and single swing door (80W-180H cm).
3. Entrance curtain:
Provided to avoid disturbance of atmospheric temperature and humidity while opening the door.
4.Floor reinforcement:
A stainless steel plate prevents dents and gouges on the floor while moving the specimen.
5. Carry-in inclined platform:
Provided below the door to facilitate moving of specimens in and out through the door.
6. Entire ceiling blow-out duct:
The extremely wide airinlet reduces the airflow rate (down to approx 0.5 m/s)
7. Plug socket:
A waterproof plug socket is provided inside the chamber, and is attached with an individual waterproof plug.
8. Temperature and humidity recorder:
Y-100-6 -50 to -100¢XC0 to100% RH 100mm Temp. 3 dots, Humid. 3 dots; Y-180-12 -50 to -100¢XC0 to 100% RH 180mm Temp. 6 dots, Humid. 6 dots.
9. Water purifier:
Provided to keep the humidifying heater and wet-bulb temperature detecting wick free from scale.
|
|
|
|
|
| |
|
|
| |
| |
 |
|
